TOA WM-5265 Handheld wireless microphone - Vocals

New UHF model (rechargeable)

Available on Channel 38 (license required)

And channel 70 (D/04) (License free)

Dynamic cardioid microphones are capable of effortlessly accommodating high input levels without overloading. For instance, the WM-5270 incorporates a pad switch that changes the maximum allowable input sound pressure from 132 dB to 142 dB to better match a wide input level range for optimal performance.

WM-5225/D04 (channel 70) & WM5225/D02

Handheld wireless microphone - speech

Specification

Microphone Element

Microphone:

Frequency Range

Channel Selectable

Maximum Input Level

Battery

Finish

Dimensions

Weight

Accessories

Dynamic

Unidirectional

576 - 865 MHz, UHF

64 channels

132 dB SPL

LR6 (AA) or WB-2000 (Ni-MH battery)

Resin coating

ø50 x 229 mm

205 g (with battery)

Microphone holder (with stand adapter),

Screw driver,

Storage case

TOA speech microphones are optimized with a frequency response tailored to emphasize clarity, thus delivering increased intelligibility. These microphones employ electret condenser elements that minimize handling-related noise, making them particularly suited for speech applications. These microphones feature a more streamlined, less bulky profile compared to conventional models, thanks to a new built-in antenna. In addition, overall weight has also been reduced, as the transmitter component now weighs less. Transmitter choices include headset types and units optimized for aerobics applications, allowing users to precisely choose a model that best suits their requirements. TOA speech microphones feature wide-area receptivity, enabling operation as far as 120 meters (when YW-4500 used) away from their tuner units. PLL-synthesized circuitry oscillation enhances carrier frequency stability and reliability, for improved performance. An at-a-glance indicator warns of low battery status, while the microphone’s single proprietary TOA battery (average operation exceeding 10 hrs.) reduces size and operating cost.

Microphone Element

Frequency Range

Channel

Maximum Input Level

Battery

Finish

Dimensions

Weight

Accessories

A trio of new wireless microphone transmitters from TOA Electronics includes the WM-5225 condenser handheld transmitter, the WM-5265 dynamic handheld transmitter, and the WM-5325 bodypack transmitter for use with lavalier and headset mics. With 64 selectable frequencies within a 30MHz band, they are rechargeable and can run up to 10 hours when used with optional AA NiMH batteries. Three charging stations are available with the largest providing 12 charging slots. All three microphone transmitters are compatible with existing 5000 series receivers as well as the WT-4820/WTU-4800 modular tuners. These models are available now on any of four frequency sets ranging from 576 MHz to 698 MHz (E01: 668-698MHz; F01: 638-668MHz; G02: 614-638MHz; and H01: 576-606MHz).

Electret condenser

576 – 865 MHz, UHF

Selectable 64 channels

126 dB SPL

LR6 (AA) or WB-2000 (Ni-MH battery)

Resin, rubber coating

ø43 × 231.5 mm

180 g (with battery)

Microphone holder

stand adapter,

The WM-5270 Wireless Microphone employs a dynamic microphone capsule with high input handling capacity and is suitable for vocal application and other professional uses. Thanks to the PLL-synthesizer system, 16 different operating frequencies (4 banks) are made available. A high output power ensures stable radio signal transmission. The maximum input sound pressure can be set in the range of 130 dB SPL to 142 dB SPL by a PAD switch, permitting adaptation to wide range of input sound pressure.

TOA WM-5270/D04 Handheld wireless microphone - Speech

New UHF model (rechargeable}

Available on Channel 38 (license required)

And channel 70 (D/04) (License free)

Dynamic

Cardioid

576 - 865 MHz, UHF

64 channels

142 dB SPL

LR6 (AA)

Resin coating

ø48 x 244 mm

340g (with battery)

Microphone holder (with stand adapter),

Rolling stopper

Storage case

Specification

Microphone Element

Microphone:

Frequency Range

Channel Selectable

Maximum Input Level

Battery

Finish

Dimensions

Weight

Accessories

TOA WM-3220/D02 Handheld

VHF wireless microphone - speech

Will replace WM270

VHF

Electret condenser cardioid microphone element.
Maximum input level: 125 dB SPL.
6 selectable channel frequencies.
On/Off switch also keeps mic from rolling when put down.
Flashing LED low battery indicator.

Specification

Microphone Element

Emission

Frequency Range

Channel Selectable

RF Carrier Power

Tone Frequency

Modulation System

Maximum Input Level

Maximum Deviation

Battery

Battery Life

Indication

Antenna

Ambient Temperature

Finish

Dimensions

Weight

Accessory

Frequency range may vary by area (between 169 to 216 MHz).

Electret condenser microphone, Cardioid

F3E

169-216 MHz, VHF* 1

6 CH

Less than 50 mW

32.768 kHz

PLL synthesizer

125 dB SPL

±40 kHz

6LR61 (9 V x 1)

More than 10 hours (alkaline)

Power/Battery indicator

Internal antenna

-10C to +50C

Resin, coating

ø45 x 235.2 mm

250 g (with battery)

Stand adapter, Screwdriver

VHF

Dynamic cardioid microphone element.
Maximum input level: 130 dB SPL.
6 selectable channel frequencies.
On/Off switch also keeps mic from rolling when put down.
Flashing LED low battery indicator.

TOA WM-3210 Handheld wireless microphone - Speech

Specification

Microphone Element

Emission

Frequency Range

Channel Selectable

RF Carrier Power

Tone Frequency

Modulation System

Maximum Input Level

Maximum Deviation

Battery

Battery Life

Indication

Antenna

Ambient Temperature

Finish

Dimensions

Weight

Accessory

Frequency range may vary by area

(between 169 to 216 MHz).

Dynamic microphone, Cardioid

F3E

169-216 MHz, VHF* 1

6 CH

Less than 50 mW

32.768 kHz

PLL synthesizer

130 dB SPL

±40 kHz

6LR61 (9 V x 1)

More than 10 hours (alkaline)

Power/Battery indicator

Internal antenna

-10C to +50C

Resin, coating

ø50 x 235.2 mm

250 g (with battery)

Stand adapter, Screwdriver

UHF

Handheld VHF transmitters, designed as optional replacements for Adastra portable PA units 952.413 can work with H25 handheld PA (952.410) or replace one of the QRPA unit microphones (178.843UK, 178.846UK) and 952.417 can replace the EZPA Lite transmitter (952.424)

Power supply

Capsule

Dimensions

Weight
