   Trantec-S4-04HD-EB-UHF-hand-radio-microphone-system-Channel-70-Lisence-free

Available from stock          £132.46  Excl VAT  (£158.95 Incl)


Overview

The S4.04 Series Handheld microphone system comes with a wireless handheld microphone and a UHF wireless receiver. Available on channel 70 with 4 switchable licence free frequencies and fully synthesized PLL quartz tuning technology.

The S4.04HD-EB is a up-dated version of the S4.4 system.

The hand microphone / tansmitter operates with 1 x AA (1.5v) battery replacing the previous PP3 (9v) with

approximately the same operating time per battery which make the new microphone less expensive to run.


Trantec S4.04 UHF system

These units on offer are on 863.150 - 863.725 - 864.150 - 864.850 so all are on channel 70.

They are NOT affected by the channel 69 switch off and still remain useable without a licence in the UK.


The Trantec S4.04 is a high quality UHF radio microphone system.


Receiver



Diversity Reception

Sensitivity

Squelch

Audio Frequency Response

Audio Output Level (Max.)



Power Supply

Dimensions

Weight

Handheld transmitter

RF Carrier Power

Audio Frequency Response

Audio Input Level

Battery Life

Power Supply

Finish

Dimensions

Weight



Trantec S4.04L-EB tie clip/pocket transmitter microphone system

Available from stock          £148.75 Excl VAT  (£178.50 Incl)

Trantec S4.04 UHF system

These units on offer are on 863.150 - 863.725 - 864.150 - 864.850 so all are on channel 70.

They are NOT affected by the channel 69 switch off and still remain useable without a licence in the UK.

Normal retail price £199.00 inc VAT + P&P

Receiver

The Trantec S4.04 is a high quality UHF radio microphone system.


Overview

Fully synthesised 4 channel PLL quartz controlled wireless microphone systems incorporating a dual conversion diversity receiver with integral Audio dynamics processor.

A comprehensive kit, ready for use, pre-programmed to use the standard UK Channel 70 frequencies (see above).  It consists of one S4.04-RX-EB GD5 receiver with power adapter, one S4.04-BTX-EBWD5 belt pack transmitter with antenna, LP2 miniature microphone, tie-clip, and foam windshield.


Beltpack  Transmitter

UHF

UHF


Diversity reception

Sensitivity

Squelch (sq)

Audio Frequency response

Audio output level



Power supply

Dimensions

Weight

Microphone

Audio Frequency response

RF carrier power

Audio input level

Battery life

Power supply

Finish

Dimensions

Weight



Antenna Diversity

10uV at 45dBA, S/N

Tone SQ, Carrier SQ, Noise SQ

50Hz – 1.5kHz

Balanced (XLR socket): -20dBu,

Unbalanced(1/4″ jack socket): 10dBu

12 VDC 500mA

215(W) x 39(H) x 102(D)mm

480g

10 mW

80 Hz – 1.5kHz

140 dSBPL (maximum)

Approx. 10 hours

1  AA size battery, 1.5V

Resin, Coating

250 x 55mm

245g with battery

Antenna Diversity

10uV at 45dBA S/N

Tone SQ, Carrier SQ, Noise SQ

50-15000Hz

Balanced XLR socket  -20dBu

Jack  Un-balanced   10dBu

11-18v  300mA

215 (w) x 39 (h) x 102 (d)mm (excluding antenna)

480g


LP2 Tie clip microphone

50-15000Hz

10mW

-6dBV (maximum) mic gain 0dB

Approx.  10 hours

1 x AA size alkaline battery  1.5v

Resin, coating

60 (w) x 100 (h) x 25 (d) mm with clip

85g with battery
